The Delta Med Surgical Hybrid TURP Resectoscope Set with Endoscopes provides a seamless, medical-grade interface between visual diagnostics and high-frequency surgical intervention. This dual-modality system eliminates the need for separate monopolar and bipolar instrument setups. Urology departments can instantly toggle between standard monopolar resection (utilizing non-conductive glycine irrigation) and advanced bipolar plasma vaporization (utilizing standard saline) significantly minimizing the risk of transurethral resection (TUR) syndrome in critical patients.
Key Performance Features
- Matched Hopkins Rod-Lens Endoscopes: The kit features wide-angle 4mm rigid telescopes engineered with premium rod-lens optics. Available in 0°, 30°, and 70° angles, they provide exceptional light transmission, color accuracy, and edge-to-edge resolution under maximum fiber optic illumination.
- Dual-Modality Working Elements: Includes both Active (spring-loaded cutting) and Passive (thumb-driven cutting) elements. Built with advanced electrical shielding, these elements manage both monopolar cutting loops and plasma-forming bipolar loops safely.
- Iglesias Continuous Flow Sheath Architecture: Combining a 24 Fr. inner sheath and a 26 Fr. outer sheath with a 360° rotating stopcock, this system maintains a perfect hydraulic equilibrium between fluid inflow and evacuation. This prevents bladder over-distension and guarantees an unobstructed view of the surgical field.
- Heavy-Duty Ceramic Beak Insulation: The distal tip of the inner sheath is armored with a highly durable, thermal-resistant ceramic compound. This structure isolates electrical arcs, eliminating the risk of accidental electrical or thermal injury to the patient's urethral mucosa.
The Delta Med Surgical Quality Standard
Every component in this combined endourological set is forged from Premium Operating Room Grade German Stainless Steel. The entire system is built to survive rigorous clinical turnaround, being fully autoclavable (134°C) and compatible with plasma or chemical gas sterilization. Manufactured under strict adherence to CE, ISO 13485, and FDA regulations.
- Complete System Configuration & Set Contents
Module A: High-Definition Endoscopes Set
- 4mm Rigid Endoscope, 0°: For accurate forward visualization during initial urethral entry and structural assessment.
- 4mm Rigid Endoscope, 30°: The workhorse lens for direct loop-cutting manipulation and tissue clearing.
- 4mm Rigid Endoscope, 70°: For retroflexed, comprehensive inspection of the bladder neck, fundus, and lateral walls.
- Universal Light Post Connections: Natively accepts ACMI, Wolf, Storz, and Olympus fiber optic cables.
Module B: Hybrid Resectoscope Instrument Set
|
Component
|
Size / Type
|
Primary Surgical Function
|
|
Hybrid Working Element (Active)
|
Thumb-Controlled / Spring Return
|
Ergonomic, rapid electrode excursion
|
|
Hybrid Working Element (Passive)
|
Finger-Controlled / Spring Forward
|
High-precision tactile cutting feedback
|
|
Inner Sheath
|
24 Fr. with Ceramic Beak
|
Holds the telescope and cutting loop securely
|
|
Outer Sheath
|
26 Fr. Continuous Flow
|
Double-lumen design for balanced drainage
|
|
Visual Obturator
|
Channel-Guided
|
Allows safe urethral advance under direct vision
|
|
Monopolar Cutting Loops
|
24/26 Fr. Compatible
|
High-precision tissue slicing
|
|
Bipolar Vaporization Loop
|
Plasma Roller / Button
|
Bloodless tissue ablation in Saline solution
|
|
High-Frequency Power Cables
|
Leakage-Protected Insulation
|
Safe power delivery from the ESU generator
|
|
Sterilization Case
|
Stainless Steel with Silicone Inserts
|
Safeguards optics and sheaths during autoclaving
|
